Aluminium Alloy Tower Erection Tools Two Bundle Conductors Overhead Lines Bicycle

Aluminium Alloy Tower Erection Tools Two Bundle Conductors Overhead Lines Bicycle
Aluminium Alloy Tower Erection Tools Two Bundle Conductors Overhead Lines Bicycle Aluminium Alloy Tower Erection Tools Two Bundle Conductors Overhead Lines Bicycle Aluminium Alloy Tower Erection Tools Two Bundle Conductors Overhead Lines Bicycle

Large Image :  Aluminium Alloy Tower Erection Tools Two Bundle Conductors Overhead Lines Bicycle

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: SFS
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 5-8workdays
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000sets/month
Detailed Product Description
Item: 17251 Model: SFS
Rated Load: 1kn Max Through Dia: 70mm
Weight: 34kg Conductor Distance: 400-500mm
High Light:

tower climbing equipment

,

tower safety equipment

Aluminium Alloy Overhead Lines Bicycles for Two Bundle Conductors



Overhead Lines Bicycles for 1/2/3/4 bundle conductors are suitable to fit aircraft warning spheres on single lines and to fit spacers on 2/3/4 bundles
Overhead Lines Bicycles for 1/2/3/4 bundle conductors
Item number Model Rated load (kN) Maximum through Diameter (mm) Conductor distance (mm) Weight (kg) Remark
17251 SFS2 1 Φ40 400 34 Horizontal
450 36
500 38
17253 SFS400 1 Φ40 400 40 Vertical
17255 FC400/450S 1 Φ60 400~450 34 Horizontal
17256 SFS1-400 1.5 Φ70 400 38 Horizontal
17257 SFS1-450 1.5 Φ70 450 40 Horizontal

Uses: to mount accessories and to overhaul.
Notes: should confirm the distance between conductors before proceeding production

Overhead Lines Bicycles for 1/2/3/4 bundle conductors are suitable to fit aircraft warning spheres on single lines and to fit spacers on two,three and four bundled conductor lines.
By pedalling forward the bicycle moves backward in order to provide the operator with necessary working space. The bicycles are equipped with disc brake on the driving wheel and with an additional safety clamp, which brakes directly on the conductor.
A meter counter and safety chains are also provided.
Special models with different characteristics can be designed on demand.
Aluminium Alloy Tower Erection Tools Two Bundle Conductors Overhead Lines Bicycle 0Aluminium Alloy Tower Erection Tools Two Bundle Conductors Overhead Lines Bicycle 1
Aluminium Alloy Tower Erection Tools Two Bundle Conductors Overhead Lines Bicycle 2
